Standard Materials of Construction:
- Sleeve - 304 SS
- Sleeve Stop - 430FR stainless steel
- Sleeve Flange - 430FR stainless steel
- Plunger - 430FR stainless steel
- Spring - 301 stainless steel
- Spool - thermoplastic
- Filter - Polyethylene
- Seals - NBR
Electrical Characteristics:
Standard Voltages
AC:24/50, 110/50, 115/50, 220/50, 230/50
DC:12, 24
Coil Classification:
Class F Standard
Class H Available
Agency Approvals:
Standard valves with DIN coils or Optional hazardous rated solenoid Enclosures to meet ATEX and International IECEx requirements. For additional details, Consult Factory.
Applications:
- Pilot Valve Actuation of Larger Control Valves
- Oil and Gas Including Off-Shore Installations
- Double Acting Cylinder Control
- Air Vices
- Air Motors
- Damper Control
